#### **Product Overview**
This product is a high-performance Hydraulic Actuator specially designed for various snow removal machines and snow removal equipment, used to drive key actions such as the lifting and adjustment of the shovel, as well as the control of the spreader. It features a design resistant to low temperatures and corrosion, enabling stable operation in extremely cold environments and ensuring the efficiency and reliability of winter snow removal operations.
---
### **Key Features**
#### **1. Adaptability to Extremely Cold Environments**
- **Low Temperature Sealing System**: Utilizes cold-resistant sealing materials (remaining elastic even at -50℃), ensuring no leakage at low temperatures
- **Compatible with Anti-freeze Hydraulic Oil**: Supports normal startup with low-temperature hydraulic oil (-45℃)
- **Heating Option**: Can be equipped with electric heating strips to prevent oil cylinders from freezing
#### 2. Anti-corrosion and Wear Resistance Design
- **Hard chrome plating on the piston rod + Teflon coating**, resistant to de-icing agent corrosion
- **Stainless steel cylinder option** (304/316 material), suitable for high-salt spray environments in coastal areas
- **Strengthened dust-proof ring**, preventing snow particles and sand from entering
#### 3. Efficient Power Output
- **Quick Response**: Startup pressure ≤ 0.5 MPa, action time ≤ 1 second
- **High Load Capacity**: Rated working pressure 25 MPa, peak pressure 35 MPa
- **Buffer Design**: Built-in hydraulic buffer to reduce impact on the shovel blade
#### 4. Modular Maintenance
- **Quick-Disassembly Sealing Bags**, enabling on-site rapid replacement
- **Standardized Interfaces**, compatible with major snow removal machine brands (BOSS, Sno-Way, etc.)
---
### **Technical Specifications**
| **Parameter** | **Specification** | |-------------------|--------------------------|
| **Work Pressure** | 16-25 MPa (customizable to 35 MPa) |
| **Temperature Range** | -50℃ ~ +80℃ |
| **Protection Grade** | IP67 (resistant to snow and water ingress) |
| **Cylinder Diameter / Rod Diameter** | 50-150mm / 25-80mm |
| **Stroke** | 200-1000mm (extendable) |
---
### **Typical Applications**
✔ **Municipal Snow Removal Vehicle** - Blade elevation, angle adjustment
✔ **Highway Roller Sweeper for Snow Removal** - Roller pressure control
✔ **Salt Spraying Machine** - Door opening and closing drive
✔ **Small Hand-Pushed Snow Sweeper** - Steering assist cylinder
---
### **Product Advantages**
✅ **Unrestricted in Extreme Cold** - Can operate normally at -50℃, resolving the issue of winter startup
✅ **Extremely Long Service Life** - Corrosion-resistant design, extending the service life by 3 times compared to conventional Hydraulic Cylinders
✅ **Easy Maintenance** - Modular design, replacing seals only takes 15 minutes
✅ **Wide Compatibility** - Supports OEM customization, matching various brands of snow removal equipment
---
### **Service Support**
- **Free Model Selection Guidance**: Recommend the best specifications based on the equipment model
- **Emergency Spare Parts Supply**: Establish winter emergency warehouses in the Northeast and Northwest regions
- **Technical Training**: Offer courses on Hydraulic System winter maintenance
